Description
Semi-Rotary Drive Daps-0720-090-Rs1-F12 Single-Acting, Air Connection As Per Vdi/Vde 3845, Namur Valves Can Be Directly Flange-Mounted Size Of Actuator=0720, Flange Hole Pattern=F12, Swivel Angle=90 Deg, End-Position Adjustment Range At0°=-1 - 9 Deg, End-Position Adjustment Range At90°=81 - 91 Deg, Festo
Specifications:
| Brand | Festo |
| Cushioning | No Cushioning |
| Material | Wrought Aluminium Alloy |
| Mounting | Any |
| Rotation Angle | 90° |
| Seal Material | Viton/Nitrile/PUR |
| Size | 720 |
| Standard | ISO 5211 |
| Thread Gender | Female |
| Thread Type | BSPP |
| Working Pressure bar | 2.8 to 8.4 |
| Working Temperature | -20°C to 80°C |
