Description
Burkert 0450 Valve – 12V DC – 0450-H-09,0-GM82-GL-012/DC is a genuine Bürkert component, ideal for maintenance, replacement and new installations. Designed for reliable performance in demanding industrial and process environments.
If you’re matching an existing unit, the order number and configuration code are the safest way to confirm compatibility. Need help cross-referencing? Roladex can assist.
Key features
- Genuine Bürkert component for industrial fluid control
- Suitable for automation, process and OEM maintenance
- Designed for dependable operation and long service life
- Specification details listed below
Properties
| CE mark | Yes |
| Main valve seal material | NBR (nitrile rubber) |
| Pilot control seal material | FKM (fluoro rubber) |
| Nominal pressure min | 2 bar |
| Nominal pressure max | 8 bar |
| Temperature ambient min | -10 °C |
| Temperature ambient max | 55 °C |
| Temperature medium min | -10 °C |
| Temperature medium max | 70 °C |
| Main valve nominal diameter 1 (P) (mm) | 9 mm |
| Voltage min / nominal voltage | 12 V |
| Voltage max / nominal voltage | 12 V |
| AC voltage | No |
| Direct voltage | Yes |
| Pre-control material in contact with medium | PA (Polyamide) |
| Pilot control material in contact with the environment | PA (polyamide) |
| Main valve material in contact with the medium | Aluminum |
| Main valve material in contact with the environment | Aluminum |
| How it works | H/Z - open in rest position - pressure port 1 to working port 2, working port 4 opened to output 5, exit 3 closed |
| Weight | 400 g / pcs |
| Customs duty number | 84812090 |
| Manufacturer | Burkert |
Supply & support
- UK supply from Roladex Industrial
- Trade pricing available
- Fast UK-wide delivery options
- Technical support for selection and equivalents
Trade Pricing & Quotes
Pricing for industrial components can vary depending on quantity, availability and lead time. Requesting a quote allows us to confirm the best price and delivery option (UK & worldwide).
What information should I include?
Please include the part number, quantity required, delivery postcode/country and any urgency or deadline.
Do you offer bulk / trade pricing?
Yes — we support trade customers, maintenance teams and OEMs with volume pricing and repeat supply.
