Description
ASAHI JBS-20 is a spherical plain bearing with 20mm bore, 46mm outside diameter. Its spherical sliding surfaces accommodate angular movement at the bearing joint.
Key verified details for this exact MPN include bore: 20mm; outside diameter: 46mm; seal/shield: Unsealed; liner: None; retention: Chamfered.
Technical Specifications
| Brand | ASAHI |
| MPN | JBS-20 |
| Product Type | Spherical Plain Bearing |
| Material | Steel/Steel |
| Bore / Inner Diameter | 20mm |
| Outside Diameter | 46mm |
| Outer Ring Width | 17.5mm |
| Ball Width | 25mm |
| Seals / Shields | Unsealed |
| Liner | None |
| Retention | Chamfered |
| Weight | 0.2 kg |
