Description
The BECO 6309-BHTSZZ-280 is a deep groove ball bearing from the BHTS ZZ 280°C range, engineered for industrial rotating applications at elevated temperature. Verified product data includes 45mm bore, 100mm OD, 25mm width, -40°C to 280°C operating range, ZZ Metal Shields, 22.86kN static load, 536rpm limiting speed.
Series characteristics: AISI 52100 Chrome Steel; 4xC5 radial clearance; PTFE-based silicone-free high-temperature grease; Lubricated for Life / No Additional Lubrication.
| Manufacturer | BECO |
| MPN | 6309-BHTSZZ-280 |
| Product Type | Deep Groove Ball Bearing |
| Series | BHTS ZZ 280°C |
| Bore | 45 mm |
| Outside Diameter | 100 mm |
| Width | 25 mm |
| Material | Steel |
| Ring Material | AISI 52100 Chrome Steel |
| Seals / Shields | ZZ Metal Shields |
| Internal Clearance | 4xC5 |
| Static Load Rating | 22.86 kN |
| Limiting Speed | 536 rpm |
| Operating Temperature | -40°C to 280°C |
| Lubrication | PTFE-based silicone-free high-temperature grease |
| Maintenance | Lubricated for Life / No Additional Lubrication |
| Weight | 830 g |
