SQN 16/5 SZ (EMC) Compact cylinders, double acting, piston 16 mm, stroke 5 mm

Genuine EMC SQN 16/5 SZ – SQN 16/5 SZ (EMC) Compact cylinders, double acting, piston 16 mm, stroke 5 mm. Designed for reliable performance in demanding industrial pneumatic systems, this component is ideal for maintenance, repair, and OEM applications.

• Part Number: SQN 16/5 SZ
• Brand: EMC
• Product Type: Pneumatic Component

Available for fast UK delivery from Roladex Industrial. Trade accounts welcome.

---

Genuine EMC SQN 16/5 SZ – SQN 16/5 SZ (EMC) Compact cylinders, double acting, piston 16 mm, stroke 5 mm. Designed for reliable performance in industrial pneumatic systems, this component is suitable for maintenance, repair, and OEM applications.

• Part Number: SQN 16/5 SZ
• Brand: EMC
• Product: SQN 16/5 SZ (EMC) Compact cylinders, double acting, piston 16 mm, stroke 5 mm

Trusted by engineers across the UK, this SQN 16/5 SZ (EMC) Compact cylinders, double acting, piston 16 mm, stroke 5 mm is available for fast nationwide delivery from Roladex Industrial Supplies.

---

Item description

Materials:
Body: anodized aluminium, piston rod: hard chromium plated steel, seal: NBR

Temperature range:
10 to +60 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D

Advantages:
•outstanding value,
•cylinder switches can be mounted on different sides,
•main mounting dimensions identical to SMC Series CQ2A (CQ2) Piston diameter [mm] 16 Stroke [mm] 5 H (piston rod thread) M 4 G (compressed air port) M 5 Repair sets SQN 16 REP A [mm] 34,0 B [mm] 30,5 C [mm] 8 D [mm] 8 E [mm] 38 F [mm] 5,5 K [mm] 6 L [mm] 3,5 M [mm] 28 N [mm] 3,4 O [mm] 6 (3,5 deep) P M 4 P1 [mm] 11,0 Q [mm] 10,0 S [mm] 29,5 U [mm] 15 V [mm] 29 Weight 80 g / pcs GTIN 4050571638603 Customs duty number 84123100 RoHS compliant Yes Manufacturer EMC
