Description
Specifications:
| Outlet Diameter | 177.8 mm (7.00 inch) |
| Inlet Diameter | 177.8 mm (7.00 inch) |
| Body Diameter Maximum | 406.4 mm (16.00 inch) |
| Overall Length | 727.71 mm (28.65 inch) |
| Body Length | 498.86 mm (19.64 inch) |
| Rated Flow LR | 17.6 m³/min (622 cfm) |
| Rated Flow MR | 21 m³/min (742 cfm) |
| Rated Flow HR | 23.7 m³/min (837 cfm) |
| Restriction LR | 14.91 mbar (5.98 inch H2O) |
| Restriction MR | 19.91 mbar (7.99 inch H2O) |
| Restriction HR | 24.91 mbar (10 inch H2O) |
| Family | FHG |
