Description
Specifications:
| Outlet Diameter | 178 mm (7.01 inch) |
| Inlet Diameter | 178 mm (7.01 inch) |
| Body Diameter Maximum | 381 mm (15.00 inch) |
| Overall Length | 660 mm (25.98 inch) |
| Body Length | 590 mm (23.23 inch) |
| Inlet Length | 241.5 mm (9.51 inch) |
| Outlet Length | 70 mm (2.76 inch) |
| Service Clearance | 540 mm (21.26 inch) |
| Rated Flow LR | 28 m³/min (989 cfm) |
| Rated Flow MR | 32 m³/min (1130 cfm) |
| Rated Flow HR | 36 m³/min (1271 cfm) |
| Family | ERB |
| Inlet Location | 136 mm (5.35 inch) |
