Description
Specifications:
| Outlet Diameter | 89 mm (3.50 inch) |
| Inlet Diameter | 114 mm (4.49 inch) |
| Body Diameter Maximum | 242 mm (9.53 inch) |
| Overall Length | 453.5 mm (17.85 inch) |
| Body Length | 322.6 mm (12.70 inch) |
| Rated Flow LR | 7.2 m³/min (254 cfm) |
| Rated Flow MR | 9 m³/min (318 cfm) |
| Rated Flow HR | 9.8 m³/min (346 cfm) |
| Restriction LR | 14.91 mbar (5.98 inch H2O) |
| Restriction MR | 19.91 mbar (7.99 inch H2O) |
| Restriction HR | 24.91 mbar (10 inch H2O) |
| Style | Radialseal |
| Family | FPG |
| Brand | RadialSeal/Alexin™ |
