Description
Specifications:
| Outlet Diameter | 101.5 mm (4.00 inch) |
| Inlet Diameter | 114 mm (4.49 inch) |
| Body Diameter Maximum | 242 mm (9.53 inch) |
| Overall Length | 487 mm (19.17 inch) |
| Body Length | 322.6 mm (12.70 inch) |
| Rated Flow LR | 7.5 m³/min (265 cfm) |
| Rated Flow MR | 8.5 m³/min (300 cfm) |
| Rated Flow HR | 9.5 m³/min (335 cfm) |
| Restriction LR | 14.91 mbar (5.98 inch H2O) |
| Restriction MR | 19.91 mbar (7.99 inch H2O) |
| Restriction HR | 24.91 mbar (10 inch H2O) |
| Style | Radialseal |
| Family | FPG |
| Brand | SCA+™ |
