Description
Specifications:
| Outlet Diameter | 101.5 mm (4.00 inch) |
| Inlet Diameter | 114 mm (4.49 inch) |
| Body Diameter Maximum | 268 mm (10.55 inch) |
| Overall Length | 488.3 mm (19.22 inch) |
| Body Length | 350.5 mm (13.80 inch) |
| Rated Flow LR | 8 m³/min (283 cfm) |
| Rated Flow MR | 9 m³/min (318 cfm) |
| Rated Flow HR | 10 m³/min (353 cfm) |
| Restriction LR | 14.91 mbar (5.98 inch H2O) |
| Restriction MR | 19.91 mbar (7.99 inch H2O) |
| Restriction HR | 24.91 mbar (10 inch H2O) |
| Style | Radialseal |
| Family | FPG |
| Brand | SCA+™ |
