Description
Specifications:
| Outlet Diameter | 88.9 mm (3.50 inch) |
| Inlet Diameter | 95 mm (3.74 inch) |
| Body Diameter Maximum | 213 mm (8.39 inch) |
| Overall Length | 432 mm (17.01 inch) |
| Body Length | 246.2 mm (9.69 inch) |
| Rated Flow LR | 3.5 m³/min (124 cfm) |
| Rated Flow MR | 5 m³/min (177 cfm) |
| Rated Flow HR | 6.2 m³/min (219 cfm) |
| Restriction LR | 9.81 mbar (3.94 inch H2O) |
| Restriction MR | 19.61 mbar (7.87 inch H2O) |
| Restriction HR | 29.42 mbar (11.81 inch H2O) |
| Style | Radialseal |
| Family | FPG |
| Brand | RadialSeal™ |
