Description
Specifications:
| Outlet Diameter | 101.5 mm (4.00 inch) |
| Inlet Diameter | 114 mm (4.49 inch) |
| Body Diameter Maximum | 259 mm (10.20 inch) |
| Overall Length | 482 mm (18.98 inch) |
| Body Length | 358.5 mm (14.11 inch) |
| Rated Flow LR | 6.6 m³/min (233 cfm) |
| Rated Flow MR | 10 m³/min (353 cfm) |
| Rated Flow HR | 13 m³/min (459 cfm) |
| Restriction LR | 9.81 mbar (3.94 inch H2O) |
| Restriction MR | 19.61 mbar (7.87 inch H2O) |
| Restriction HR | 29.42 mbar (11.81 inch H2O) |
| Style | Radialseal |
| Family | FRG |
