Description
Specifications:
| Outlet Diameter | 152 mm (5.98 inch) |
| Inlet Diameter | 178 mm (7.01 inch) |
| Body Diameter Maximum | 381 mm (15.00 inch) |
| Overall Length | 600 mm (23.62 inch) |
| Body Length | 446.5 mm (17.58 inch) |
| Rated Flow LR | 20.2 m³/min (713 cfm) |
| Rated Flow MR | 22.8 m³/min (805 cfm) |
| Rated Flow HR | 26.7 m³/min (943 cfm) |
| Restriction LR | 14.91 mbar (5.98 inch H2O) |
| Restriction MR | 19.91 mbar (7.99 inch H2O) |
| Restriction HR | 24.91 mbar (10 inch H2O) |
| Style | Radialseal |
| Family | FRG |
| Brand | RadialSeal™ |
