Description
Specifications:
| Outlet Diameter | 203.2 mm (8.00 inch) |
| Inlet Diameter | 439 mm (17.28 inch) |
| Body Diameter Maximum | 406.4 mm (16.00 inch) |
| Overall Length | 750.82 mm (29.56 inch) |
| Width | 457 mm (17.99 inch) |
| Body Length | 345.44 mm (13.60 inch) |
| Rated Flow LR | 38.5 m³/min (1360 cfm) |
| Rated Flow MR | 44.4 m³/min (1568 cfm) |
| Rated Flow HR | 49.8 m³/min (1759 cfm) |
| Restriction LR | 14.91 mbar (5.98 inch H2O) |
| Restriction MR | 19.91 mbar (7.99 inch H2O) |
| Restriction HR | 24.91 mbar (10 inch H2O) |
| Style | Peripheral |
| Family | STG |
| Brand | Donaclone™ |
