Description
Specifications:
| Outlet Diameter | 177.8 mm (7.00 inch) |
| Inlet Diameter | 177.8 mm (7.00 inch) |
| Body Diameter Maximum | 406.4 mm (16.00 inch) |
| Overall Length | 668.3 mm (26.31 inch) |
| Width | 511 mm (20.12 inch) |
| Body Length | 345.44 mm (13.60 inch) |
| Rated Flow LR | 25.9 m³/min (915 cfm) |
| Rated Flow MR | 30.1 m³/min (1063 cfm) |
| Rated Flow HR | 34 m³/min (1201 cfm) |
| Restriction LR | 14.91 mbar (5.98 inch H2O) |
| Restriction MR | 19.91 mbar (7.99 inch H2O) |
| Restriction HR | 24.91 mbar (10 inch H2O) |
| Style | Tubular |
| Family | STG |
| Brand | Donaclone™ |
