Description
Specifications:
| Inlet Diameter | 127.64 mm (5.03 inch) |
| Outlet Diameter | 127.64 mm (5.03 inch) |
| Body Diameter Maximum | 227.84 mm (8.97 inch) |
| Body Length | 508 mm (20.00 inch) |
| Overall Length | 673 mm (26.50 inch) |
| Rated Flow LR | 40.5 m³/min (1430 cfm) |
| Rated Flow MR | 57.3 m³/min (2024 cfm) |
| Rated Flow HR | 70.1 m³/min (2476 cfm) |
| Back Pressure Low-Range | 25 mm Hg (0.98 inch Hg) |
| Back Pressure Mid-Range | 51 mm Hg (2.01 inch Hg) |
| Back Pressure High-Range | 76 mm Hg (2.99 inch Hg) |
| Attenuation LR | 10 dBA |
| Attenuation HR | 15 dBA |
| Style | Style 1 |
