Description
Specifications:
| Inlet Diameter | 127.64 mm (5.03 inch) |
| Outlet Diameter | 127.64 mm (5.03 inch) |
| Body Diameter Maximum | 255.5 mm (10.06 inch) |
| Body Length | 1124 mm (44.25 inch) |
| Overall Length | 1295.4 mm (51.00 inch) |
| Rated Flow LR | 49.9 m³/min (1762 cfm) |
| Rated Flow MR | 70.6 m³/min (2493 cfm) |
| Rated Flow HR | 83.5 m³/min (2949 cfm) |
| Back Pressure Low-Range | 25 mm Hg (0.98 inch Hg) |
| Back Pressure Mid-Range | 51 mm Hg (2.01 inch Hg) |
| Back Pressure High-Range | 76 mm Hg (2.99 inch Hg) |
| Attenuation LR | 16 dBA |
| Attenuation HR | 23 dBA |
| Style | Style 1 |
