Description
Item description
Operating pressure:max. 700 bar
Temperature range:
-20 to +65 °C
Scope of delivery:
All cylinders (except for type RH 120) are supplied with a mounted coupling sleeve type 9796.
Advantages:
•Ideal for pulling and tensioning cables, extracting bolts, anchoring screws and pressure spindles.
| Lifting force [to (Kraft)] | 60 |
| Stroke [mm] | 152,4 |
| oil volume [cm³] | 1211,3 |
| Height retracted [mm] | 311,2 |
| Centre hole diameter [mm] | 54,0 |
| External thread cylinder | UN 6-1/4"-12 |
| Cylinder diameter (outer) [mm] | 158,8 |
| Weight | 45 kg / pcs |
| GTIN | 4050571578114 |
| Customs duty number | 84122120 |
| Manufacturer | SPX Power Team |
