Description
Genuine Aventics pneumatic valve.
| Manufacturer | Aventics |
| MPN | 5727505280 |
| Product Type | Pneumatic Valve |
| Series | Series 740 |
| Voltage | 230AC |
| Manual override | not latching |
| Outlet connection | Ø 8x1 |
| Nominal flow Qn | 700 l/min |
| Ambient temperature max. | 50 °C |
| Ambient temperature min. | -15 °C |
| Exhaust connection | M14x1 |
| Input connection | Ø 8x1 |
| Operating pressure max. | 10 bar |
| Operating pressure min. | 3 bar |
| Electrical interface | EN 175301-?803, Form A |
| Operating voltage V AC 50 Hz | 230 V |
| Operating voltage V AC 60Hz | 230 V |
| SAP short text | V740-?5/4CC-?DI06-230AC-07 |
For technical assistance, equivalents, or bulk enquiries, contact us.
