Description
Strong, pliable gasket is compressed against the air cleaner housing to create a tight seal.
• High-efficiency cellulose media performs across a wide range of heavy-duty engine applications.
• Corrosion resistant, coated steel liners support media during operation and help maximize airflow.
• Pleatloc™ feature ensures uniform pleat spacing and prevents media from bunching to promote longer service life.
• High-efficiency cellulose media performs across a wide range of heavy-duty engine applications.
• Corrosion resistant, coated steel liners support media during operation and help maximize airflow.
• Pleatloc™ feature ensures uniform pleat spacing and prevents media from bunching to promote longer service life.
Specifications:
| Overall Length | 623.1 mm (24.53 inch) |
| Outer Diameter | 323.6 mm (12.74 inch) |
| Inner Diameter | 212.9 mm (8.38 inch) |
| Length | 610.4 mm (24.03 inch) |
| Bolt Hole Diameter | 23.62 mm (0.93 inch) |
| Efficiency | 99.9 |
| Efficiency Test Std | ISO 5011 |
| Family | FVG |
| Type | Primary |
| Style | Round |
| Media Type | Cellulose |
