Description
Safety filters have two functions: to act as a backup to the primary filter and to protect the engine during primary filter servicing.
• Serve as a backup filter in case of primary filter damage or improper installation.
• Prevent contaminants from entering the clean side of the air intake system during primary filter servicing.
• Designed to plug rapidly if contamination finds its way past the primary filter, alerting operators about an issue.
• Recommend that safety filters are replaced with every third primary filter change unless there has been a failure of the primary filter.
• Serve as a backup filter in case of primary filter damage or improper installation.
• Prevent contaminants from entering the clean side of the air intake system during primary filter servicing.
• Designed to plug rapidly if contamination finds its way past the primary filter, alerting operators about an issue.
• Recommend that safety filters are replaced with every third primary filter change unless there has been a failure of the primary filter.
Specifications:
| Outer Diameter | 141.2 mm (5.56 inch) |
| Inner Diameter | 106.7 mm (4.20 inch) |
| Length | 268.5 mm (10.57 inch) |
| Bolt Hole Diameter | 16.76 mm (0.66 inch) |
| Efficiency Test Std | ISO 5011 |
| Primary Application | KOMATSU 6114807101S |
| Type | Safety |
| Style | Round |
