Description
• High-performance Hydraulic Cartridges utilize Donaldson media technology which undergoes stringent design and testing which sets the standard in filtration performance.
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic cartridges for greater contamination control.
• A variety of WilFit cartridges which meet and/or exceed OEM specifications.
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic cartridges for greater contamination control.
• A variety of WilFit cartridges which meet and/or exceed OEM specifications.
Specifications:
| Seal Material | Nitrile |
| Outer Diameter | 117 mm (4.61 inch) |
| Inner Diameter | 59 mm (2.32 inch) |
| Length | 163 mm (6.42 inch) |
| Gasket OD | 85 mm (3.35 inch) |
| Gasket ID | 60 mm (2.36 inch) |
| Overall Length | 166 mm (6.54 inch) |
| Efficiency Beta 1000 | 23 micron |
| Collapse Burst | 10.3 bar (149 psi) |
| Style | Cartridge |
| Media Type | Synthetic |
| Primary Application | ARGO V2121708 |
