Description
• High-performance Hydraulic Cartridges utilize Donaldson media technology which undergoes stringent design and testing which sets the standard in filtration performance.
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic cartridges for greater contamination control.
• A variety of WilFit cartridges which meet and/or exceed OEM specifications.
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic cartridges for greater contamination control.
• A variety of WilFit cartridges which meet and/or exceed OEM specifications.
Specifications:
| Outer Diameter | 72 mm (2.83 inch) |
| Inner Diameter | 27.9 mm (1.10 inch) |
| Length | 121.4 mm (4.78 inch) |
| Gasket OD | 32.05 mm (1.26 inch) |
| Gasket ID | 24.99 mm (0.98 inch) |
| Overall Length | 124.2 mm (4.89 inch) |
| Efficiency Beta 200 | 11.5 micron |
| Efficiency Beta 1000 | 15 micron |
| Efficiency Test Std | ISO 16889 |
| Bypass Valve Setting HR | 4.14 bar (60 psi) |
| Collapse Burst | 10.3 bar (149 psi) |
| Maximum Operating Temperature | 107 °C (225 °F) |
| Style | Cartridge |
| Media Brand | Synteq XP™ |
| Primary Application | BOBCAT 6692337 |
