Description
• High-performance Hydraulic Spin-On filters utilize Donaldson media technology which undergoes stringent design and testing which sets the standard in filtration performance.
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM specifications
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM specifications
Specifications:
| Outer Diameter | 127 mm (5.00 inch) |
| Thread Size | M48 x 2 |
| Length | 174 mm (6.85 inch) |
| Gasket OD | 124 mm (4.88 inch) |
| Gasket ID | 112 mm (4.41 inch) |
| Efficiency Beta 2 | 7 micron |
| Efficiency Beta 75 | 16 micron |
| Efficiency Beta 200 | 19 micron |
| Efficiency Beta 1000 | 23 micron |
| Efficiency Test Std | ISO 4548-12 |
| Collapse Burst | 6.9 bar (100 psi) |
| Style | Spin-On |
| Media Type | Cellulose |
