Description
• High-performance Hydraulic Spin-On filters utilize Donaldson media technology which undergoes stringent design and testing which sets the standard in filtration performance.
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM specifications
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM specifications
Specifications:
| Outer Diameter | 136 mm (5.35 inch) |
| Thread Size | 1 1/2-16 UN |
| Length | 305 mm (12.01 inch) |
| Efficiency Beta 2 | 17 micron |
| Efficiency Beta 75 | 39 micron |
| Efficiency Test Std | ISO 4548-12 |
| Bypass Valve | Yes |
| Bypass Valve Setting LR | 1.7 bar (25 psi) |
| Collapse Burst | 6.9 bar (100 psi) |
| Style | Spin-On |
| Media Type | Cellulose |
