Description
Specifications:
| Inlet Diameter | 153.39 mm (6.04 inch) |
| Outlet Diameter | 153.39 mm (6.04 inch) |
| Body Diameter Minimum | 307.85 mm (12.12 inch) |
| Body Diameter Maximum | 460.25 mm (18.12 inch) |
| Body Length | 762 mm (30.00 inch) |
| Overall Length | 965.2 mm (38.00 inch) |
| Rated Flow LR | 61.5 m³/min (2172 cfm) |
| Rated Flow MR | 87 m³/min (3072 cfm) |
| Rated Flow HR | 106.5 m³/min (3761 cfm) |
| Back Pressure Low-Range | 25 mm Hg (0.98 inch Hg) |
| Back Pressure Mid-Range | 51 mm Hg (2.01 inch Hg) |
| Back Pressure High-Range | 76 mm Hg (2.99 inch Hg) |
| Attenuation LR | 11 dBA |
| Attenuation HR | 16 dBA |
| Inlet Clock Position | 3:00 |
| Outlet Clock Position | 9:00 |
| Style | Style 2 |
