Description
Specifications:
| Inlet Diameter | 127.64 mm (5.03 inch) |
| Outlet Diameter | 127.64 mm (5.03 inch) |
| Body Diameter Maximum | 300.7 mm (11.84 inch) |
| Body Length | 654 mm (25.75 inch) |
| Overall Length | 804.9 mm (31.69 inch) |
| Rated Flow LR | 49.9 m³/min (1762 cfm) |
| Rated Flow MR | 69.3 m³/min (2447 cfm) |
| Rated Flow HR | 69.3 m³/min (2447 cfm) |
| Back Pressure Low-Range | 25 mm Hg (0.98 inch Hg) |
| Back Pressure Mid-Range | 51 mm Hg (2.01 inch Hg) |
| Back Pressure High-Range | 51 mm Hg (2.01 inch Hg) |
| Attenuation LR | 12 dBA |
| Attenuation HR | 18 dBA |
| Inlet Clock Position | 6:00 |
| Style | Style 3/Style 4 |
