Description
Specifications:
| Brand | INA |
| MPN | LR5306-X-2Z-TVH-XL |
| Material | Steel |
| ID - Inner Diameter | 30mm |
| OD - Outer Diameter | 80mm |
| Width | 30.2mm |
| Basic dynamic load rating, radial [C r w] | 36000 N |
| Basic static load rating, radial [C 0r w] | 29500 N |
| Speed on permanent grease lubrication [n D G] | 4750 1/min |
| Seals / Shields | 2 Metal Shields |
| Weight (kg) | 0.67 |
