Description
Specifications:
| Brand | INA |
| MPN | GRAE35-XL-NPP-B-FA125.5 |
| Material | Steel |
| ID - Inner Diameter | 35mm |
| OD - Outer Diameter | 72mm |
| Width | 25.4mm |
| Basic dynamic load rating, radial | 25500 N |
| Locking Collar Total Width | 39mm |
| Basic dynamic load rating, radial [C r] | 25500 N |
| Basic static load rating, radial [C 0r] | 15300 N |
| Seals / Shields | Sealed |
| Locking Method | Eccentric Collar - Flat Back |
| Weight (kg) | 0.45 |
