Description
The BECO 6309-BHTS-330 is a deep groove ball bearing from the BHTS 330°C range, engineered for industrial rotating applications at elevated temperature. Verified product data includes 45mm bore, 100mm OD, 25mm width, -20°C to 330°C operating range, Open / Unsealed, 22.06kN static load, 67rpm limiting speed.
Series characteristics: AISI 52100 Chrome Steel; 4xC5 radial clearance; Molybdenum Disulphide Grease + High-Temperature Oil; Requires Automatic Oil Lubrication.
| Manufacturer | BECO |
| MPN | 6309-BHTS-330 |
| Product Type | Deep Groove Ball Bearing |
| Series | BHTS 330°C |
| Bore | 45 mm |
| Outside Diameter | 100 mm |
| Width | 25 mm |
| Material | Steel |
| Ring Material | AISI 52100 Chrome Steel |
| Seals / Shields | Open / Unsealed |
| Internal Clearance | 4xC5 |
| Static Load Rating | 22.06 kN |
| Limiting Speed | 67 rpm |
| Operating Temperature | -20°C to 330°C |
| Lubrication | Molybdenum Disulphide Grease + High-Temperature Oil |
| Maintenance | Requires Automatic Oil Lubrication |
| Weight | 830 g |
