SQN 12/20 SZ (EMC) Compact cylinders, double acting, piston 12 mm, stroke 20 mm

Genuine EMC SQN 12/20 SZ – SQN 12/20 SZ (EMC) Compact cylinders, double acting, piston 12 mm, stroke 20 mm. Designed for reliable performance in demanding industrial pneumatic systems, this component is ideal for maintenance, repair, and OEM applications.

• Part Number: SQN 12/20 SZ
• Brand: EMC
• Product Type: Pneumatic Component

Available for fast UK delivery from Roladex Industrial. Trade accounts welcome.

---

Genuine EMC SQN 12/20 SZ – SQN 12/20 SZ (EMC) Compact cylinders, double acting, piston 12 mm, stroke 20 mm. Designed for reliable performance in industrial pneumatic systems, this component is suitable for maintenance, repair, and OEM applications.

• Part Number: SQN 12/20 SZ
• Brand: EMC
• Product: SQN 12/20 SZ (EMC) Compact cylinders, double acting, piston 12 mm, stroke 20 mm

Trusted by engineers across the UK, this SQN 12/20 SZ (EMC) Compact cylinders, double acting, piston 12 mm, stroke 20 mm is available for fast nationwide delivery from Roladex Industrial Supplies.

---

Item description

Materials:
Body: anodized aluminium, piston rod: hard chromium plated steel, seal: NBR

Temperature range:
10 to +60 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D

Advantages:
•outstanding value,
•cylinder switches can be mounted on different sides,
•main mounting dimensions identical to SMC Series CQ2A (CQ2) Piston diameter [mm] 12 Stroke [mm] 20 H (piston rod thread) M 3 G (compressed air port) M 5 Repair sets SQN 12 REP A [mm] 31,5 B [mm] 28,0 C [mm] 6 D [mm] 6 E [mm] 33 F [mm] 6,5 K [mm] 5 L [mm] 3,5 M [mm] 22 N [mm] 3,4 O [mm] 6 (3,5 deep) P M 4 P1 [mm] 11,0 Q [mm] 11,0 S [mm] 27,5 U [mm] 14 V [mm] 25 Weight 80 g / pcs GTIN 4050571638504 Customs duty number 84123100 RoHS compliant Yes Manufacturer EMC
