Description
• High-performance Hydraulic Spin-On filters utilize Donaldson media technology which undergoes stringent design and testing which sets the standard in filtration performance.
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM specifications
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM specifications
Specifications:
| Outer Diameter | 96 mm (3.78 inch) |
| Thread Size | 3/4 BSP/G |
| Length | 144 mm (5.67 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Efficiency Beta 2 | 10 micron |
| Efficiency Beta 75 | 30 micron |
| Efficiency Beta 1000 | 36 micron |
| Efficiency Test Std | ISO 4572 |
| Collapse Burst | 10 bar (145 psi) |
| Style | Spin-On |
| Media Type | Cellulose |
