Description
• High-performance Hydraulic Spin-On filters utilize Donaldson media technology which undergoes stringent design and testing which sets the standard in filtration performance.
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM specifications
• Donaldson Media Formulations provide superior hydraulic system protection.
• Donaldson offers the largest selection of replacement hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM specifications
Specifications:
| Outer Diameter | 93.98 mm (3.70 inch) |
| Thread Size | M24 x 1.5 |
| Length | 151.38 mm (5.96 inch) |
| Gasket OD | 71.37 mm (2.81 inch) |
| Gasket ID | 62.48 mm (2.46 inch) |
| Efficiency Beta 2 | 19 micron |
| Bypass Valve | Yes |
| Bypass Valve Setting LR | 2.1 bar (30 psi) |
| Style | Spin-On |
| Media Type | Cellulose |
