Description
Genuine EMC ZDM 16/50 E – ZDM 16/50 E (EMC) ISO 6432 cylinders, double acting, piston 16 mm, stroke 50 mm. Designed for reliable performance in demanding industrial pneumatic systems, this component is ideal for maintenance, repair, and OEM applications.
- Part Number: ZDM 16/50 E
- Brand: EMC
- Product Type: Pneumatic Component
Available for fast UK delivery from Roladex Industrial. Trade accounts welcome.
Genuine EMC ZDM 16/50 E – ZDM 16/50 E (EMC) ISO 6432 cylinders, double acting, piston 16 mm, stroke 50 mm. Designed for reliable performance in industrial pneumatic systems, this component is suitable for maintenance, repair, and OEM applications.
- Part Number: ZDM 16/50 E
- Brand: EMC
- Product: ZDM 16/50 E (EMC) ISO 6432 cylinders, double acting, piston 16 mm, stroke 50 mm
Trusted by engineers across the UK, this ZDM 16/50 E (EMC) ISO 6432 cylinders, double acting, piston 16 mm, stroke 50 mm is available for fast nationwide delivery from Roladex Industrial Supplies.
Item description
Materials:Head and foot: anodized aluminium, cylinder tube: 1.4301, piston rod: 1.4305, seal: NBR
Temperature range:
-20 to +80 °C
Operating pressure:
max. 10 bar
Version:
With Magnetic piston
Cylinder switch type:
D in combination with fastening D1, C in combination with fastening C1
| Piston diameter [mm] | 16 |
| Stroke [mm] | 50 |
| Version | Standard |
| A (piston rod thread) | M 6 |
| B (fastening thread) | M 16x1,5 |
| G (compressed air port) | M 5 |
| A1 [mm] | 6 |
| C [mm] | 21,8 |
| D [mm] | 12 |
| E [mm] | 6 |
| F [mm] | 16 |
| G [mm] | 82 |
| K [mm] | 22 |
| L [mm] | 17 |
| M [mm] | 111 |
| N [mm] | 9 |
| P [mm] | 56 |
| CH [mm] | 5 |
| Weight | 125 g / pcs |
| GTIN | 4050571930516 |
| Customs duty number | 84123100 |
| RoHS compliant | Yes |
| Manufacturer | EMC |
